DSL-32/48 High Speed Automatic Electronic Counting Machine
The DSL-32/48 High Speed Automatic Electronic Counting Machine is designed for large-scale production, offering ultra-high counting speeds with 32 or 48 channels. It features advanced anti-dust technology, multi-stage vibration feeding, and high accuracy for tablets, capsules, and softgels, fully complying with GMP standards.
- Ultra High Speed & Accuracy (>99.97%)
- 32 or 48 Counting Channels
- High Anti-Dust Sensor Technology
- Multi-Stage Vibration Feeding
- GMP Compliant (Stainless Steel)
Product Description
The DSL-32/48 series represents the pinnacle of high-speed counting technology. Designed for mass production, these machines utilize 32 or 48 channel vibration feeding to achieve exceptional output rates. The high anti-dust photoelectric detection technology ensures accurate counting even with high-dust tablets.
Features include a multi-stage vibration system for optimal material separation, ensuring no jams or overlaps. Intelligent functions such as bottle detection (no bottle, no count), automatic rejection of abnormal bottles, and self-diagnosis are standard. The entire operation is managed via a Siemens PLC and touch screen, making it user-friendly and easy to integrate into full packaging lines.
Main Features
- Massive Capacity: Capable of handling very high output requirements (up to 150 bottles/min).
- Superior Compatibility: Counts all types of solid dosage forms: tablets, capsules, softgels, pills, and candy.
- Advanced Anti-Dust: Proprietary sensor technology guarantees accuracy in dusty environments.
- Precision Feeding: Multi-stage vibration tracks ensure consistent and smooth material flow.
- Intelligent Operation: Real-time monitoring, auto-stop protection, and fault alarm system.
- Easy Cleaning & Maintenance: Tool-free disassembly of key components for quick cleaning.
Technical Parameters
| Model | DSL-32 | DSL-48 |
|---|---|---|
| Counting Channels | 32 Channels | 48 Channels |
| Output Capacity | 40 - 120 bottles/min | 40 - 150 bottles/min |
| Applicable Object | Capsules, Tablets, Pills, Softgels | Capsules, Tablets, Pills, Softgels |
| Counting Range | 1 - 9999 pcs/bottle | 1 - 9999 pcs/bottle |
| Power | 2.2 KW | 2.5 KW |
| Voltage | 220V 60Hz | 220V 60Hz |
| Dimensions (L*W*H) | 2200 × 1400 × 1680 mm | 2160 × 1650 × 1650 mm |
| Weight | 550 kg | 680 kg |
Applications
The DSL-32/48 High Speed Automatic Electronic Counting Machine is ideal for:
- Large Pharmaceutical Manufacturers: For high-volume production lines of tablets and capsules.
- Nutraceutical Industry: Mass packaging of vitamins, supplements, and fish oil softgels.
- Confectionery Industry: High-speed counting of candies, mints, and gums.
- Contract Packaging: Efficient handling of large orders with quick changeover capabilities.
Customization Service
At Hanyoo, we understand that every production line is unique. We provide comprehensive customization services to ensure the Counting Machine perfectly fits your facility and production requirements.
Mold & Tooling
Customized counting channels and nozzles for different tablet shapes and bottle neck sizes.
Layout & Integration
We design the machine layout to fit your factory space and integrate seamlessly with your existing production line.
Voltage & Power
Electrical components tailored to your local voltage standards (220V/110V, 50Hz/60Hz) for global compatibility.
GMP Documentation
Full set of validation documents (DQ, IQ, OQ, PQ) and material certificates provided for GMP compliance.
